KCL-XG Glass Laser Cutting Machine

Short Description:

Model: KCL-XG

Warranty : 3 Years

Application:

1) Construction industry: used to make glass products such as doors, windows, curtain walls, partitions, etc. to improve the aesthetics and lighting effects of buildings.

2) Home decoration: Make various exquisite glass furniture , lamps, ornaments, etc. to add artistic atmosphere to home life.

3) Automobile manufacturing: used for cutting automobile windshields, door glass and other parts to improve automobile safety and aesthetics.

4) Electronic products: cutting glass parts for precision electronic products such as mobile phone screens and tablet screens, Meet the requirements of modern electronic products for thin, The pursuit of beauty.
5) Handicraft production: Carve exquisite patterns and texts to create unique works of art and souvenirs.

6) Solar industry: Cutting glass substrates for solar panels to improve solar energy utilization efficiency.

Send email to us

Product Detail

Product Tags

Serial number	project		unit	Laser Cutting
1.	Maximum processing size of glass		mm	2440x3660
2.	Single-blade processing glass thickness		mm	≤19
3.	Glass laser cutting speed		m/min	7-25 (depending on glass thickness)
4.	Processing laser wavelength		nm	1064
5.	Processing laser power		W	80W@20KHz@Burst5
6.	Repetition frequency		KHz	20-40
7.	Pulse Energy		mJ	4
8.	Number of pulses			5-6
9.	Power stability			< 0.5%@24 hours , rms
10.	Laser pulse width		ps	~15
11.	Beam quality			M²≤ 1.3
12.	Operating humidity			<60%RH@25 ℃
13.	Cooling method			Water Cooling
14.	Split laser type			Carbon dioxide laser
15.	CO2 Laser wavelength			10.6 um
16.	C02 Laser power			300W
17.	Glass laser splitting comprehensive speed		m/min	6-18 (depending on glass thickness)
18.	Environmental resistance	Storage temperature	℃	20 ~ 35
19.		Operating temperature	℃	twenty two ~ 30
20.		Ambient humidity		< 60 %
twenty one.		dust	mg/m³	< 0.20
twenty two.		Oil mist		Not allowed
twenty three.		Electromagnetic environment		International secondary standard
